Circuit identification labels. Name the equipment.
A circuit label has to let a person “readily identify the equipment supplied and the corresponding circuit protective devices”. That is Energy Safe Victoria’s test for clause 2.10.5.2 (EIS 007).
- What
- Engraved circuit labels, one per breaker, to your wording. Adhesive back or screw holes.
- Price
- From $1.83 for one 15 x 10 mm label, inc GST. 40 x 12 mm: $2.22.
- How fast
- Engraved in 1 to 3 business days, then 2 to 6 by standard post.
- How to order
- Type the wording below, pick a size, pay. A numbered run is one line.
The clauses ESV names
AS/NZS 3000:2018, as Energy Safe Victoria cites it. We have not read the paid standard. These are the regulator's pages, in plain words.
- 2.10.5.1
- Switchboard equipment identification, general. On the ESV Top 10 general defects list. (Energy Safe Victoria, electrical installation defects)
- 2.10.5.2
- Label each circuit breaker and RCBO to show what part of the installation or what equipment it supplies. (Energy Safe Victoria, EIS 007)
- 2.10.5.4
- Mark or arrange the terminals so each circuit's active and neutral can be matched. ESV's example: neutrals for C1 and C2 not marked at the neutral bar. (Energy Safe Victoria, EIS 007)
- 2.10.4.3(d)(ii)
- A separate neutral bar terminal for each outgoing circuit. This one is about terminals, not labels. (Energy Safe Victoria, EIS 007)
- 2.3.3.5
- Main switch identification. On ESV's COES audit defect list. (Energy Safe Victoria, electrical installation defects)
In NSW, safety services switches carry their own wording under clause 7.2.4.4 and contrast in colouring under 2.3.3.4 (Building Commission NSW, Advisory Note 3/2021). The wording is below.
Against ESV's test
The test is whether someone who did not wire the board can tell what each breaker feeds. Our reading: two breakers both labelled KITCHEN do not say which feeds what, and CB4 GPOs KITCHEN EAST does.
Exact wordings
Word for word from the regulator pages. Copy them.
MAIN SWITCH (INVERTER)
Main switch for the inverter supply, solar installs
AS/NZS 4777.1:2024 cl 6.3(a), shown by Solar Victoria, Solar PV audit checklist: Switchboard
MAIN SWITCH (GRID)
Main switch for the grid supply. The checklist also allows (Mains) or (Normal)
AS/NZS 4777.1:2024 cl 6.3(b), shown by Solar Victoria, Solar PV audit checklist: Switchboard
MAIN ISOLATOR (GRID)
Main isolator for the grid supply. Also (Mains) or (Normal)
AS/NZS 4777.1:2024 cl 6.3(c), shown by Solar Victoria, Solar PV audit checklist: Switchboard
IN THE EVENT OF A FIRE, DO NOT TURN OFF
Safety services main switches, in upper case. The same clause asks for contrast in colouring or other suitable means, per cl 2.3.3.4
AS/NZS 3000 cl 7.2.4.4(b), shown by Building Commission NSW, Advisory Note 3/2021
A 24-way board, named
Room plus side or use, never the room alone. KITCHEN on two breakers tells nobody which is which. CB4 GPOs KITCHEN EAST does.
| Breaker | Label |
|---|---|
| CB1 | LIGHTS LOUNGE DINING |
| CB2 | LIGHTS BEDS 1-3 HALL |
| CB3 | LIGHTS KITCHEN OUTDOOR |
| CB4 | GPOs KITCHEN EAST |
| CB5 | GPOs KITCHEN WEST BENCH |
| CB6 | GPOs LOUNGE DINING |
| CB7 | GPOs BEDS 1-2 |
| CB8 | GPOs BED 3 STUDY |
| CB9 | GPOs LAUNDRY |
| CB10 | GPOs GARAGE |
| CB11 | OVEN |
| CB12 | COOKTOP |
| CB13 | DISHWASHER |
| CB14 | HOT WATER |
| CB15 | AIRCON LOUNGE |
| CB16 | AIRCON BED 1 |
| CB17 | POOL PUMP |
| CB18 | EV CHARGER GARAGE |
| CB19 | SMOKE ALARMS |
| CB20 | MAIN SWITCH (INVERTER) |
| CB21 | SPARE |
| CB22 | SPARE |
| CB23 | SPARE |
| CB24 | SPARE |
Built for this example, not a real job. Numbering the neutral terminals to match (N4 for CB4) is one way to mark them, which is what the ESV 2.10.5.4 defect is about. The whole set is 24 labels at 40 x 12 mm: paste them into From a list in the designer.
Sizes and prices
The circuit label sizes people order, with labels ordered in April to October 2026.
| Size | Labels ordered | 1 label, inc GST | Designer |
|---|---|---|---|
| 40 x 12 mm | 96 | $2.22 | Design at 40 x 12 |
| 25 x 8 mm | 37 | $1.89 | Design at 25 x 8 |
| 15 x 10 mm | 93 | $1.83 | Design at 15 x 10 |
| 18 x 15 mm | 60 | $1.97 | Design at 18 x 15 |
| 60 x 20 mm | 152 | $3.08 | Design at 60 x 20 |
One label in the lowest-priced stocked colour, from the same engine as the designer. The price per label drops with quantity.
Numbered runs: type PUMP 1, pick Numbered, set To 26. PUMP 1 to PUMP 26 is one line in the cart, not 26. Open the designer at 40 x 12 with PUMP 1.
What the regulator pages do not say
None of the regulator pages we read gives a text height for AS/NZS 3000 labels or names a label material. None mentions Dymo or adhesive labels.
The only letter heights are for solar and battery signs: 5 mm upper case and 4 mm lower case per metre of viewing distance, as a recommendation (Solar Victoria, technical guidance sheet 2.4, Clean Energy Council, Advice on Labelling (v2, June 2023)).
Order today →
Standard $8.50, free over $40
Tue 20 Oct to Wed 28 Oct
Express $15
Mon 19 Oct to Fri 23 Oct
Priority Air $35
Mon 19 Oct to Thu 22 Oct
What customers are saying
All reviews“Hi recently had solar panels installed, but the installer did a messy job on my switchboard. The moved all the switches around, but didn't move any of the existing labels, and the new labels were just label maker and the terminology was non complaint (failed and Office of the Technical Regulator audit). I took it on myself to get professionally laser cut labels to replace the dodgy label maker/hand written and non-compliant language. RBZ3D was easy to use to make all the labels I need, shipped quick enough, and now the labels look so much better. Would definitely recommend and use again.”
Quick answers.
What does a circuit identification label have to do?
Energy Safe Victoria's test for AS/NZS 3000 clause 2.10.5.2 is whether the labelling lets a person "readily identify the equipment supplied and the corresponding circuit protective devices" (EIS 007). Name the equipment each breaker supplies.
Which AS/NZS 3000 clauses cover circuit labels?
ESV names 2.10.5.1 (switchboard equipment identification), 2.10.5.2 (what each circuit breaker or RCBO supplies) and 2.10.5.4 (active and neutral terminals marked or arranged to match). It names 2.3.3.5 for main switch identification.
Is there a minimum text height for circuit labels?
None of the regulator pages we read gives one for AS/NZS 3000 labels. Solar Victoria and the Clean Energy Council recommend 5 mm upper case and 4 mm lower case per metre of viewing distance, for solar and battery signs.
What size are circuit breaker labels?
April to October 2026, by labels ordered: 40 x 12 mm (96), 25 x 8 mm (37), 15 x 10 mm (93), 18 x 15 mm (60), 60 x 20 mm (152). Any other size is priced by area in the designer.
How do I order a numbered run?
Type the first label (PUMP 1), pick Numbered, set To 26. PUMP 1 to PUMP 26 is one line in the cart, not 26.
More to ask? See the full FAQ or call Josh on 0432 736 559.
Send the schedule.
A photo of the board or a typed circuit list. Pricing comes back within 24 hours.
Josh is a licensed electrician, so board questions are fine.
